Automatic Square Frame Filter Press (630 mm Plates)
Model: SU40/630-U
Informațiile despre produs sunt în curs de completare — specificațiile și prețurile afișate sunt orientative și nu constituie o ofertă.
Categorie
Mașini industriale
Material
Q345B carbon steel frame / PP filter plates
Origine
China
Timp de livrare
25-35 days
Ambalare
Seaworthy export packing: anti-corrosion coating, stretch film, wooden case for the control cabinet
Certificări
Manufactured to ISO 9001 practice; CE documentation available on request
Stare
Disponibil
Descriere produs
A fully automatic square-plate filter press for dewatering slurry in wastewater, chemical and mineral processing plants. Thirty-five 630 × 630 mm polypropylene chambers close under a hydraulic ram at 18–22 MPa and hold pressure automatically, so a single operator can run a full cycle without manual clamping. The frame is welded Q345B carbon steel with a box-type main beam; the hydraulic station, oil hoses and control cabinet are built for continuous duty, with an explosion-proof cabinet available for solvent-bearing slurry.
Specificații
Model:
SU40/630-U
Plate Size:
630 × 630 mm
Plate Thickness:
50 mm
Number of Chambers:
35
Filter Cloth:
35 sets (incl. head and tail plate cloths)
Cake Thickness:
approx. 25 mm
Chamber Volume:
approx. 434 L
Filtration Area:
10 m²
Overall Dimensions:
3550 × 870 × 1150 mm
Main Unit Weight:
approx. 1,605 kg
Feed Pressure:
≤ 0.8 MPa
Closing Pressure:
18–22 MPa
Feed Opening:
DN50 flange, centre feed
Discharge:
gravity, dual outflow
Drive:
horizontal motor, high-pressure oil pump (explosion-proof)
Foundation Centre Distance:
1000 mm
Caracteristici principale
- ✓ 35 chambers close hydraulically and hold pressure automatically — no manual clamping
- ✓ Box-type Q345B main beam welded by automatic submerged arc, with internal bracing to resist deformation
- ✓ PP plates and cloths rated for acid and alkali service
- ✓ Explosion-proof control cabinet, split type or mounted on the main unit
- ✓ Pressure protection: process relief below 25 MPa, return line below 10 MPa
- ✓ Larger filtration areas available on request
Aplicații
Sludge dewatering at municipal and industrial wastewater plants, tailings and concentrate dewatering in mining, chemical and pharmaceutical slurry, and food-processing waste streams.
